BASSPRO NANO
Ultra-Compact Under Seat Powered Subwoofer System
JBL BassPro Nano delivers bumping bass and takes up little space. The on-board 100Wrms amplifier has been performance matched to subwoofer to deliver the amount of clear, tight bass.
JBL's BassPro NANO delivers deep bass and takes up little space. JBL's smallest powered subwoofer can be hid in the most compact of locations and deliver exceptional performance to any car audio system. Its rugged all-die-cast aluminum enclosure with anodized textured matte black finish, which looks great. Powered by a 100Watt Amplifier, BassPro Nano delivers punchy, tight bass you would expect from JBL, all while running cool and drawing minimal current from your vehicles charging system.
Intelligent Electronic Design for Reliable and Extraordinary Performance
The BassPro Nano employs high-pass filters and limiters that deliver exceptional at-the-limits performance.
Features:
6"x8"(152mmx203mm) Subwoofer 100Wrms; 200W Max
Frequency: 30Hz – 150Hz
Fuse: 15A
Maximum Current Draw: 13 A
0.1 V – 4.0 V Low-Level Input; 0.25 V – 20V High-Level Input
Crossover Frequency: 50 Hz – 150 Hz
Crossover Slope: 12 dB/octave
Bass Boost: 0dB to + 12dB @ 50Hz
Dimensions (L x W x H): 10-1/4" x 7-11/16" x 2-15/16"(260.0mm x 195.0mm x 74.6mm)
*By request/order.
